• Directional from 20 Hz to 20 kHz
Dipole polar pattern
4.8 dB diffuse noise rejection
>20 dB noise rejection at the null Dual sound ports
• Differential or singled-ended output
• 63.5 dBA SNR
• Low THD:
1% THD at 116 dB SPL
AOP at 131 dB SPL (Standard Mode)
AOP at 134 dB SPL (High-AOP Mode)
• 115 µA supply current
• 3.50 x 2.65 mm2 footprint
• -40 to 85 °C operating temperature
